Timeguard Din Rail Mount 24 Hour Segment Timeswitch (3 Module)

Timeguard Din Rail Mount 24 Hour Segment Timeswitch (3 Module)

You need to be logged in to see prices.

A 52.5mm (3 module) wide segment 24 hour 16A timeswitch.

  • 16(4)A analogue timeswitch
  • 1 channel
  • Daily program
  • Without power reserve
  • 96 switching segments
  • Synchronised with mains
  • Shortest switching time: 15 minutes
  • Clock hands for time display and in addition 12/24 hour recognition
  • Simple summer/winter time correction
  • Time can be changed clockwise or anti-clockwise
  • DuoFix spring terminals for 2 conductors each
  • Wire or strand (with or without wire end sleeve)
  • Wire diameter: 0.5 – 2.5 mm²
  • Button for releasing plug-in connection
  • Switching preselection
  • Manual switch with 3 positions: Continuous ON/AUTO/continuous OFF
  • Switching status display

No detailed specifications are available for this product.
